直线式锁盖机
特点Feature:
For different types of bottles, users may only need to adjust the cap drop lane, bottle clamping belt, the distance between the capping wheels and the height of the working box.
对于不同规格的容器,只要调整落盖机的通道、锁盖机的夹瓶皮带、锁盖轮间的距离和工作机箱的高低即可。
优点advantage：
automatic cap delivery mechanism, 自动盖子传送机构
Automatic error lids remover will pick out the caps which is in wrong direction, and bottle sensor for no bottle no capping, assure good capping effect and less error. 自动纠错盖卸盖器将方向错误的瓶盖自动挑出，瓶盖传感器无瓶不上盖，保证盖上效果好，误差小。
刻度调节机构，便于调节用于不同瓶子尺寸Calibration adjustment mechanism， easy adjust for different bottle size.
For different types of bottles, users may only need to adjust the cap drop lane, bottle clamping belt, the distance between the capping wheels and the height of the working box.
对于不同规格的容器,只要调整落盖机的通道、锁盖机的夹瓶皮带、锁盖轮间的距离和工作机箱的高低即可。
主要技术参数Technical Parameters:
Model
型号
SGP-200
Capacity
生产能力
50-100 bottles/minute depend on your bottle
Cap Diameter
适合瓶盖直径
Φ 25-Φ 70mm
Vessel Diameter
适合容器直径
Φ 35-Φ 140mm
Vessel Height
适合容器高度
38-250 mm
Power Supply
总功率
3P AC 380V 50-60 Hz
Power Consumption
电源
1.2 KW
Main Machine Dimensions (L × W × H)
主机外形尺寸
1300 × 850 × 1400mm
Main Machine Weight
主机重量
600Kg
Cap Dropper Dimensions (L × W × H)
上盖机尺寸
1100 × 1200 × 2150 mm
Cap Dropper Weight
上盖机重量
190kg
自动液体灌装旋盖一体机
特点Feature:
Automatic Filling and Capping machine for the application of light liquid filling and capping for plastic or glass bottles. The machine is composed by a conveyor, SS316L volumetric piston pump, top-bottom filling nozzles, liquid buffer tank, bottle index wheel, capping system.
自动灌装旋盖机适用于塑料或玻璃瓶的轻液体灌装旋盖。该机由输送带、SS316L计量柱塞泵、上下灌装喷嘴、液体缓冲罐、分度轮、旋盖系统组成。
优点advantage：
装量调整方便，可一次调整全部计量泵的充填量 the filling volume can be conveniently adjusted, the filling volume of all metering pumps can be adjust in one step
灌装头设计有防滴漏装置，防止气泡 the filling system is provided with the anti-leaking device and avoiding bubbles
设备适合不同规格瓶子，调整方便 the machine is suitable for various kinds of bottle and adjustments conveniently.
technical parameters
型号Model
YAMP8/2
YAMP4/1
灌装量filling volume
20~1000ml
可选灌装量filling pump range
20-100ml 50-250ml100-500ml200ml-1000ml
盖子种类cap type
Alternative Screw on cap, alum. ROPP cap
产量capacity
3600~5000bph
2400~3000bph
灌装精度Filling accuracy
≤±1％
旋盖精度 capping accuracy
≥99％
电源power supply
220V 50/60Hz
功率power
≤2.2kw
≤1.2kw
气压air pressure
0.4~0.6MPa
重量weight
1000kg
800kg
尺寸size
2200×1200×1600
2000×1200×1600
